Space-Saving Side Drive Spiral Conveyor System

The Side Drive Spiral Conveyor revolutionizes vertical conveying by eliminating the need for a traditional large central drum. Unlike cage-style spirals, this system utilizes a unique side-drive mechanism that engages the edge of the modular belt, allowing for a more open, accessible, and sanitary structure.

Engineered for flexibility, the system can handle elevations up to 10 meters with customizable tier spacing. Its simplified design requires only a single drive motor, significantly reducing energy consumption and maintenance complexity compared to traditional drum spirals. Whether you are cooling baked goods or elevating packaged cartons, this conveyor delivers smooth, continuous flow with a lower total cost of ownership.

Key Features

Space-Saving Design: Maximizes vertical space utilization with a compact footprint, ideal for facilities with limited floor space.

Hygienic Open Structure: The drum-less design eliminates dirt traps and allows for easy wash-downs and airflow, making it perfect for food safety standards.

Energy Efficient: Powered by a single drive motor, reducing energy usage and simplifying electrical controls compared to multi-drive systems.

Low Maintenance: Fewer moving parts and a simplified drive system result in minimal wear and easier maintenance routines.

Flexible Configuration: capable of reaching heights up to 10 meters with adjustable tier spacing (80mm – 800mm) to accommodate various product sizes.

Modular Belt System: Features a robust modular plastic belt that is easy to repair and replace.

Technical Specifications

Applications

The Side Drive Spiral Conveyor is highly versatile and suitable for a wide range of industries:

1. Direct Food Handling (Naked Products)

Ideal for processing lines requiring cooling, proofing, or freezing.

Bakery: Cooling and proofing of bread, buns, and pastries.

Ready Meals: Transporting pizzas and prepared foods.

Protein & Produce: Conveying fresh meat, poultry, and vegetables.

2. Packaging & Logistics

Perfect for end-of-line solutions and vertical elevation of light to medium-weight goods.

Packaged Goods: Cartons, boxes, and shrink-wrapped trays.

Containers: Plastic crates, totes, and bins.
